Yellow 2 Axis Linear Lcd Lathe Machine Dro For Machine Tools
Product Introduction
The principal design philosophy of ES-14 is to provide the higher noise immunity readout system in the market. Extreme careful PCB and component layout that strictly follows all known rules to achieve highest possible noise immuity and EMC performance, linear power supply is used in to ensure highest possible performance in noise immunity to the electrical source.
DRO
* Displaying as 8 digits with green LED.
* Aluminum casing,industrial quality.
* High integration makes the performance be stable.
* Light touch button service life more than 100000 times.
Ultra Low Temperature Rise Transformer
Easson all Digital readout system's power supply use a voltage switch linear power transformer and power filter, this can help our products pass by the noice immunity and the EMC.
To reduce the total heat generation inside the ES DRO in order to obtain long working life. An ultra low temperature rise transformer that construct with very high permeability icron core is used, which effectively bring temperature rise to only about 5℃.
EMC Testing equipment
To Make sure all Easson DRO products can be pass the standard EMC standard specification, we have a complete set of EMC test esd immunity tester.
Technical Specification
| Model number | ES-14 | ||
| Axis number | 2 Axis | ||
| Axis Display resolution | 0.1μm, 0.5μm, 1μm, 5μm | ||
| Signal Output | TTL | ||
| Voltage | AC110 V - 220 V / 50Hz - 60Hz | ||
| Gross Weight (kg) | 3.5 | ||
|
Input frequency |
2 MB Hz | ||
| Keyboard | Light touch buttons | ||
| Operating temperature | 0℃ - 45℃ | ||
| Storage temperature | -40℃ - 55℃ | ||
| Relative humidity | ≤ 95% | ||
| Inputs | 3 optical linear scale | ||
| EMC Standard |
IEC61000-4-2 / GB / T 17799-2 IEC61000-4-4 / GB / T 17799-4 IEC61000-4-5 / GB / T 17799-5 |
||
Basic parameter is included as below:
Connector interface
| PIN | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 |
| TTL Signal | --- | 0V | --- | GND | --- | A | 5V | B | R |
| Cable | --- | Orange | --- | Ground | --- | Yellow |
