Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder

Certification
China Zhuhai Easson Measurement Technology Ltd. certification
China Zhuhai Easson Measurement Technology Ltd. certification
Customer Reviews
This DRO display is smaller than most and i am very happy with it. The controls are simplified and i have had no problem mastering it and using all features. I'm 71 years old. The Display information is bright white and very easy to see in all lighting conditions even with my poor eye sight. No green or red led lights to have to look at anymore.

—— F***b

Unit is legit and works and is very nice but I still have to set it up but this is much better than traditional dro displays. It shows the operations for the different functions it has.

—— A***r

Material conforms to the order very well packs works very well. Very fast shipment after Chinese New Year

—— John

The seller is very helpful and the product quality is excellent 06 May 2022 11:01

—— M***e

I'm Online Chat Now

Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder

Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder
Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder
Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder

Large Image :  Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder

Product Details:
Place of Origin: P.R.China
Brand Name: Easson
Certification: CE
Model Number: SP-3020
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Packaging Details: Plywood Case
Delivery Time: 5 working days
Payment Terms: T/T
Supply Ability: 25 Sets per Month

Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder

Description
Name: Cnc Vision Measuring System Keyword: Cnc Vision System
Meas.Accuracy: (1.5+L/200)um Meas. Travel: 300x200x200mm
CCD: High Resolution SONY CMOS Camera Display Resolution: 0.01μm Absolute Scale
Operation Model: Automatic Repeatability: 0.002mm
High Light:

Video Cmm Measurement Machine

,

Visual Cmm Measurement Machine

,

Cmm Measurement Machine



SP3020 CNC Automatic Vision Measuring Machines With 3 Axis 0.01μm Linear Encoder



Product Characterisitics


  • Three axis equipped a resolution 0.01 μm Absolute Linear Encoder Scale
  • F3 high precision closed loop auto zoom lens.
  • Special designed motion controller of Vision measuring machine using Ethernet transmission, which is efficient and reliable system, can solve the disadvantage of unstable USB transmission.
  • High resolution SONY CMOS image processor to ensure the image is excellent and without smearing.
  • The up light source using eight areas partitioned independent control lighting system, and the light-emitting element using low-attenuation LED to extend working life.
  • Powerful measurement software, the measurement results can be output to DXF, Word, Excel, PDF and AutoCAD.

Technical Specification




Model SP-3020 SP-4030 SP-6050
Measuring Travel(mm) 300x200x200 400x300x250 600x500x300
Overall Dimension (mm) 1200x720x1600 1250x900x1600 1350x1000x1850
Work Table Glass Size(mm) 339x239x10 439x339x12 648x548x18
Weight (kg) 280 410 1700
Max Table Load(kg) 30 30 30
Measurement Accuracy (μm) 1.5+L/200 2+L/150
Repeatability(μm) 2
Magnification Optical Magnification 0.7-4.5X, Image Magnification 20-125X
Axis Display Resolution 0.00001mm (0.01μm)
Lighting System Eight areas up light source with two laser positioning system
Operation Model Automatic, control by mouse, joystick or keyboard
Lens Automatic Zoom, automatic focus optical coaxial lens
Vision System High-resolution SONY CMOS global shutter camera





F3 high precision closed loop auto zoom lens




Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder 0Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder 1

Features:



1. 3 million pixels high resolution lens

2. Fully closed-loop servo control eliminates gear transmission gap and greatly improves the repeatability of the machine.

3. Adopt the high precision and resolution ring shaped grating ruler specially developed and designed by our company for F3 Lens for full closed-loop position feedback.

4. F3 lens comes with a coaxial light source to solve the problem of insufficient illumination for deep hole measurement.

5. Fully closed-loop servo position feedback for fully automatic focusing





The three Axis of SPARTAN  series adopt the AC servo motor system, recognized by  the industry as one of the most reliable system, to make sure high speed and reliable measuring.

Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder 2





21 Items Volumetric Compensation




Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder 3



Easson Vision Measurement Machine used with AR series Network control System which is included 21 orders volumetric compensation, with Ultra high speed linear encoder reading and built-in EAD (absolute scale decoder) allow AR series system to use the AS-80 high precision absolute scale, providing high accuracy and high resolution measurement.



Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder 4

Visual Video Cmm Measurement Machine With 3 Axis 0.01μm Linear Encoder 5

Easson Measurement Technology Ltd. was established since 1995, is a high-tech enterprise for over 20 years in design and manufacturing precision measuring equipment, such as Video Measuring Systems, profile projector, DRO(counter), linear glass ruler, CNC linear encoder;



Easson have actively participated in standard committee's work, seriously work together with other pioneering companies in this industry to boost the development of this industry in China.



Easson is one of the few companies in this industry that equipped with master mask manufacturing facilities, all master mask of our absolute linear grating are built in house and with our registered trademark to prevent being illegal copied.
